Cabinet-style fiber laser markingmachine

Applicable Materials:

All metals and some non-metallic materials.

Applicable Industry:

It is mainly used to mark various plastic buttons andelectronic devices, and to mark codes on CMOS chips,color papers and food packaging. It can also be used indemanding ranges such as clocks, jewelry, modules,bitmap markers and more.

GET A QUOTE

Description

Benefit

1. lmported high speed galvanometer scanner. (chinese brand opti-onal}

2.Repeatability up to 0.05mm.3. Safe, no harm to the skin.4. Red dot pointer quickly marks the speed.5. The operation is simple and convenient, easy to learn and easyto operate.

6. The structure is stable and the vibration during opera tion is small.

7. Adopt air cooling method.

8.Run without maintenance.

Laser Type	Fiber laser	Laser Wavelength	1064nm
Laser power	20W/30W/50W/100W	Software	EzCad
Marking Area	110X110/200X200/300X300mm	Max speed	7000mm/s
Line Width	0.01-0.1mm	Min Character	0.3mm
Cooling way	Air cooling	Beam Quality	Less than 1.4 M2
Input Power	0.5KW	Packing Size	1150X920X760mm
Graphic Format Supported	BMP,GIF,JPGEPCXTIFF,PLT,CDR,DMG etc	Voltage	AC220V±10%/AC110V±10%
Net/Gross Weight	90KGS/110KGS	Optional parts	Rotary attachment
