UV laser marking machine
Applicable Materials
The materials with heat radiation reaction,some specialmaterials,most metal and nonmetal material. Mainlythe higher marking precision such as mobile phonesbuttons, plastic translu-cent keys, electronic components,integrated circuits (lC),electrical appliances,communication products, sanitary ware, tools, acce-ssories, knives, eyeglasses and clocks, jew-elry, autoparts, luggage buckle, cooking utensils, stainless steelproducts and other industries.
Applicable Industry
It is applied in ultra-fine laser marking in highend market.It can mark and engrave on toys wood. UV Laser MarkingMachine adopts UV laser generator .The ultra-small focu.sing spot of 355nm UV light doesn't break the surface ofglass.There is no heating effects when marking,so it wouldnot deform the lenses and upper.The machine can mark,cut and engrave for special materials.
Laser Type |
UV laser |
Laser Wavelength |
355nm |
Laser power |
5W/10W |
Software |
EzCad |
Marking Area |
110X110/200X200mm |
Max speed |
Less than 30000mm/min |
Laser Frequency |
10-150kHZ |
Reprtition precision |
±0.01mm |
Cooling way |
Water cooling(with a chiller) |
Beam Quality |
1.2-1.8M2 |
Marking depth |
Less than 0.2mm |
Packing Size |
80*40*90cm |
Graphic Format Supported |
BMP,GIF,JPGEPCXTIFF,PLT,CDR,DMG etc |
Voltage |
AC220V±10%/AC110V±10% |
Net/Gross Weight |
65KGS/70KGS |
Optional parts |
Rotary attachment |
Process materials |
Metal and part of non metal |
Power consumption |
Less than 1600W |
